2D Piping Layout & Detail Engineering for Leading Brewery in Indonesia

Design Engineering Success Story 4
Project Scope
  • Piping / Equipment layout detail engg. & drafting
  • Cable tray route layout & detail drawings
  • The areas are as follows – Guinness cellar, CIP hot/cold supply, Separator / cooler distribution, Cold wort distribution, Deareated water distribution, Yeast storage, Waste yeast tank, Gyle & Lager yeast storage and Carbo blend section
Systems and Tools
  • AutoCAD Mechanical
  • AutoCAD Electrical
Inputs
  • P&ID and Plot plan
  • Equipment fabrication details
Outputs
  • 2D Piping / equipment layout & detail engg
  • Pipe rack & support detail engg.
  • Equipment fabrication drawings
  • Sectional views and Bill of material
  • Isometrics and As-Built drawings
  • Site visit & information collection
